Drilling Mud Testing Equipment & Procedures

Drilling Mud Testing Equipment & Procedures | Physical

Drilling Mud Testing Equipment & Procedures

The following drilling mud testing equipment & procedures have been standardized in accordance with internationally accepted ANSI/ API RP 13B-1 Fourth Edition, March 2009 (Recommended Practice for Field Testing Water-Based Drilling Fluids), which is identical to ISO 10414-1: 2008 (Field Testing of Drilling Fluids Part 1 for Water-Based Mud). But first, before going in-depth on our subject, let’s have a look at Safety Precautions While Mud Testing

Drilling Mud Testing Equipment & Procedures For Physical Properties

API and Pressurized Mud Balances for Density

There are two drilling mud testing equipment & procedures for measuring mud density, the API Mud Balance and the Pressurized Mud Balance. The API Mud Balance is suitable for simpler mud systems in top-hole intervals, while the Pressurized Mud Balance is preferred for deeper intervals because it gives more accurate results by reducing errors due to aeration and compressibility.

Water Based Mud Testing Procedures For Mud Density article handles the right procedures for Mud balance, pressurized mud balance & tru-wat cup,

Marsh Funnel for Viscosity

The Marsh Funnel is a simple drilling mud testing equipment for measuring funnel viscosity and its procedures are so easy. The Marsh Funnel holds around 1.5 liters of fluid and is filled by pouring mud through the wire-mesh screen for removing solids that might block the narrow discharge tube at the base of the funnel. The time taken for 1 quart (946 ml) of mud to flow out of the discharge tube, measured using a mud cup, is then recorded as a time in seconds, thicker muds obviously taking longer than thinner muds.

Water Based Mud Testing Procedures For March Funnel Viscosity article handles the right procedures for using march funnel with related papers to calculate apparent viscosity from march funnel viscosity, You will find also a video shows how to use the march funnel.

Viscometer for Rheology

A viscometer or rheometer is used for obtaining fluid rheology (apparent viscosity, plastic viscosity, yield point, and gel strengths) (check also Yield Point In Drilling Mud Formula), which is a measure of the resistance of a fluid to flow. Several models are available, powered by a hand-crank or electric motor. The instrument comprises a solid pivoted cylindrical bob that is restrained by a torsion spring and connected to a torsion dial. The cylindrical bob sits inside a cylindrical outer sleeve that can be rotated at selected speeds, with a narrow annular clearance between the bob and the sleeve.

Water Based Mud Rehometer | Viscometer Testing Procedures article handles the right procedures for using Rheometer or Viscometer, You will find also a video that shows how to use the rheometer.

Drilling Mud Testing Equipment & Procedures For API Filter Press (WBM only)

The low temperature API filter press test, which is operated at room temperature and low pressure is utilized for estimating fluid loss only with Water Based Mud.

Water Based Mud API Filter Press Testing Procedures article handles important hints about this drilling mud testing equipment and the test procedures. In addition to that, you shall find detailed procedures and a video explaining these procedures.

HPHT Filter Press Fluid Loss Test Procedure

The HPHT filter press is useful for determining the quality of the oil-water emulsion in Oil Based Drilling Mud. The presence of “free water” in the filtrate is an indication that the emulsion is weak and, if this is the case, more emulsifier should be added to the oil-based mud to prevent deterioration in drilling performance.

HPHT Filter Press Testing Procedures article not only focuses on the procedures but also you will find the potential problems due to excessive filtrate invasion, excessive cake thickness with related videos and scientific papers.

Drilling Mud Testing Equipment & Procedures For Sand Content

It is so important to determine the sand content in drilling fluids as if its percent is high, a thick filter cake will be expected to be formed on the wellbore hole or the sand may settle down in the bottom of the hole when the mud pumps are off. Also excessive sand content will result in excessive abrasion of the mud pump and any pipe connections.

Sand Content In Drilling Mud Test Procedure article explains, in brief, the procedures according to API for the test and gives you an idea about the sand content kit. In addition to that, you will find related videos and scientific papers.

Retort Analysis Drilling Fluid for Oil, Water and Solids Content

Retorts are available with  10  ml,  20  ml and  50 ml retort chamber capacities, the 50 ml chamber providing greater accuracy. It is important to make sure that the discharge tubes in the retort chamber assembly and condenser do not get plugged, as will then build up in the retort chamber

Retort Analysis Drilling Fluid Article explains the right API procedures and calculations For oil, water & solid contents

Drilling Mud Testing Equipment
